正品 7英寸液晶显示 航行警告接收机HX2600(NAVTEX RECEIVER)

详细描述

1.接收频率:518KHz、490KHz、486KHz及4209.5KHz.
2.可同时接收通道：
双通道（即一个接收机工作在518KHz通道，另一个接收机可以

(490KHz/486KHz/4209.5KHz)之间切换
3.灵敏度：
有用信号电平在-107dBm时，中文误码率小于1%,英文误码率小于4%。
4.选择性抗干扰性能：
阻塞抑制比：按照IEC61097-6标准规定频率的强信号干扰下，收到

有用信号中文误码率小于1%,英文误码率小于4%。
5.天线保护：
在天线端加上无调制信号幅度为emf 30V
频率范围100KHz~28MHz,15分钟之后设备仍可正常工作。
6.显示器规格：
7英寸彩色屏显示器
7.信息存储功能:
可存储200条信息,平均每条信息500字符,存储时间为60~72小时。
被标记信息可以永久保存,用户不可自行删除。
8.外部接口:1个INS接口、1个打印输出接口、USB接口。
9.可配置SII-DPU-414类型的热敏打印,输出接口电器格式RS-232
10.发声报警:音量不小于75dBA~85dBA。
11.电源：12VDC~36VDC
12.主机重量：1135克
13.本技术条件的法规依据:IMO ResolutionMSC148(77)、

IEC 61097-6、IEC 60945(2002)。

能通过岸台识别码Bl的选择自动拒牧不需要的报文信息。
能通过对报文种类识别码B2的选择对某些类型的报文不予显示、打印或
发送到INS接口，但A、B、D、L类报文除外。
有信号处理器、液晶显示器、INS接口、天线保护、信息存储器等是否
能正常工作的自检功能。
显示器每行至少能显示47个字符，至少能显示12行信息文本。
收到不清楚的字符显示一个"*"符号。
每个接收器至少能稳定存储200条平均长度为500个字符的信息。
能存储个别长度达到8000个字符的信息。
每个接收器内部可以存储200个信息识别标记。
能避免显示或存储已经正确接收过的报文信息。
在接收到经过60-72小时后，信息自动从存储器中被清除。如果接收
到的信息超过了存储容量，则先到的信息被自动清除。
当误码率大于33%时接收机不存储或显示这些报文信息和信息标识。
该设备的存储器的代码资料不会因为6个小时的电源供应中断而被清除。

1. Receive Frequency: 518KHz, 490KHz, 486KHz and 4209.5KHz.
2. Can receive channels:
Dual-channel (ie, a receiver operating in 518KHz channel, and the other

receivers in the 490KHz / 486KHz/4209.5KHz switch between)
3. Sensitivity:
Useful at-107dBm signal level, the bit error rate of less than 1% of Chinese

and English error rate of less than 4%.
4. Selective anti-jamming performance:
Blocking rejection ratio: In accordance with IEC61097-6 standards for frequency

of strong signal interference, receive helpful information No less than 1% error rate

in Chinese and English error rate of less than 4%.
5. Antenna Protection:
In the antenna signal with no modulation amplitude emf30V Frequency range of

100KHz ~ 28MHz, 15 minutes after the device is still working properly.
6. Monitor specifications: 7-inch color screen display
7. Information storage function:
Can store 200 messages, with an average of 500 characters each message, the

storage time of 60 - 72 hours. Tag information can be stored permanently and

you can not manually delete the.
8. External interface: an INS interface, a print output interface, USB interface.
9. Can be configured SII-DPU-414 type of thermal printing, the output format

RS-232electrical interfaces
10. Sound the alarm: the volume of not less than 75dBA ~ 85dBA.
11. Power supply: 12VDC ~ 36VDC
12. Weight: 1135 g
13. The technical conditions of the legal basis: IMO ResolutionMSC148 (77),

IEC 61097-6, IEC 60945 (2002).

ID Bl shore station through the choice of animal husbandry and do not automatically

reject the message information.
through the ID of the message type of option B2 certain types of packets will not display,

print or Sent to the INS interface, but the A, B, D, L type, except the message.
a signal processor, LCD display, INS interfaces, antenna protection, information storage,

such as whether Self-test function to work properly.
At least each line display can show 47 characters, at least 12 rows of information display text.
receive a clear display of characters "*" symbol.
At least each receiver can stably store 200 average length of 500 characters of information.
8000 can store the length of individual characters of information.
Each receiver 200 can store information within the identification tag.
to avoid the display or storage has been correctly received packets of  information.
The received after 60-72 hours, information is automatically cleared from memory.

If the receiver To more information than the storage capacity, the first of the information

 is automatically cleared.
When the error rate is more than 33%, the receiver does not store or display the message

information and information identification.
The device's memory code information will not be six hours of power supply interruption is cleared
