正品 日本FURUNO古野具有CCS、EC双重认证 船用 甚高频FM-8900S

FURUNO古野VHF RADIOTELEPHONE 　FM-8900S船用甚高频电台

甚高频无线电话规格标准：
VHF：EN 301 925 V1.3.1 (2010-09)
VHF ATIS：EN 300 698-1 V1.4.1 (2009-12)
DSC：ITU-R M.493-13 (10/2009) / ITU-R M.541-9 (05/04) / ITU-R M.689-2 (09/94) / EN 300 338-1 V1.3.1 (2010-02) / EN 300 338-2 V1.3.1 (2010-02)
发射类别：G3E(Radiotelephone)，G2B(DSC)
通信：单/半双工
信道：所有VHF信道符合ITU-R无线电规则
显示：4.3寸 WQVGA 分辨率彩色液晶屏
发射频率：155.000 - 161.475 MHz
射频输出功率：25W，可减少至1W
频率稳定性：由于±1.5KHz
发射超时：不间断发射超过5分钟以后，停止发射。
ATIS(发射机自动识别系统)：发射结束时发送 1300和2100 Hz调制信号。
接收机频率范围：单工 155.000～159.600MHz；半双工 161.475～164.200MHz 接收系统：
接收灵敏度：20dB信纳比时小于6dBμV
邻频道选择性：≥70dB
两次超外差第一中频：51.1375 MHz
第二中频：62.5 kHz
音频功率：内置扬声器3W (4ohms. ≤10％失真)
DSC信息记录：
接收50条遇险信息、50条非遇险信息，50条发射信息。
接口：IEC61162-1导航信息，并口打印机接口（兼容PP-510）
报警：接收到DSC呼叫后发出听觉和视觉报警
DSC频率：156.525 MHz (CH70)
DSC灵敏度：0dBμV时误码率≤1％
电源：24VDC,0.6A(待机),1.8A(接收),4.7A max.(发射)
防水等级：IP20

FURUNO VHF/DSC : FM-8900S

Full GMDSS-compliant VHF radiotelephone with Class-A DSC facility
and CH70 watch receiver
Meets the new ITU recommendation on digital selective
calling system for use in the Maritime Mobile Service, ITU-R M.493-13

�7�4 FEATURES

• Semi-duplex 25-Watt VHF radiotelephone with a built-in Class-A DSC
and CH70 watch Receiver
• Fully meets GMDSS carriage requirements for SOLAS ships
• Easy to read, high-contrast 4.3" bright color LCD
• Enhanced noise reduction and speaker for superb voice quality
• Quick access to CH16 key
• Easy channel selection with rotary control or direct keypad input
• Automatic entry of own ship position and time through the interfaced GPS receiver
• ATIS signal transmission available for inland waterways
• Connect to an office or home via an existing PSTN
(Public Switched Telephone Network)

�7�4 SPECS
• RF OUTPUT POWER : 25 W
• TX FREQUENCY RANGE : 155.000 to 161.475 MHz
• RX FREQUENCY RANGE Simplex : 155.000 to 159.600 MHz
• Semi-duplex : 161.475 to 164.200 MHz
• COMMUNICATION SYSTEM : Simplex, Semi-duplex
• CLASS OF EMISSION : G3E (Radiotelephone), G2B (DSC)
• DISPLAY : 4.3 inches WQVGA (480x272 dots),
• color dot matrix LCD
• POWER SUPPLY : 24 VDC

�7�4 EQUIPMENT LIST
Standar
• VHF Radiotelephone FM-8900S 1unit
• Handset HS-2003 1unit
• Handset Cradle FP05-05510 1unit
• Installation materials and spare parts 1set
Option
• Junction Box ： IF-8900
• Remote Station ： RB-8900
• Watertight Remote Station ： RB-8900-W
• Handset and Cradle
• Flush Mount Kit ： OP05-129
• External Loudspeaker ： SEM-21Q
• Printer ： PP-8800A/PP-510
• Printer Interface ： IF-8500
• AC/DC Power Supply ： Unit PR-240
• VHF Console ： RC-8900

VHF/DSC

MODEL : FM-8900S
